IU Window V1

We will use this page as an alternative place to host solutions and instructions, a summary of each solutions, whether the solutions is currently in testing and what other Ukrainians think of the solution.

Polyethylene Triple Glazed Window - English

Summary: This solution uses polyethylene, PVC piping, pipe insulation and duct tape, to create 4 layers of insulation. The solution insulates better than double glazed windows.

Proposed by: Max-Olivier Van Bastelaer, Harry Blakiston Houston, Michael Blakiston Houston

Polyethylene Triple Glazed Window - Ukrainian

Summary: This solution uses polyethylene, PVC piping, pipe insulation and duct tape, to create 4 layers of insulation. The solution insulates better than double-glazed windows.

Materials

  • PVC piping 25mm to build frame

  • Polyethylene sheet 150-micron UVI stabilised

  • Pipe insulation 28mm with 9mm wall thickness.

  • HPX duct tape.

  • Adhesive PU foam

  • Tools

    • PVC pipe cutters

    • Screws

    • Stanley knife

How it works

This solution is similar to triple glazing. In our case support is provided by a frame made from PVC piping. Around this frame, we wrap a single sheet of polyethylene. We secure this polyethylene using the insulation noodle attached to the frame. We then wrap the outer frame using more polyethylene. This results in a triple-glazed polyethylene sheet. In case you wish to protect against rain and other elements you can strap a sacrificial sheet to the outside of the window.

Instructions
